I wanted to use responsive images for my small page of cute cats (now removed as of 8/12/2024). Since one of the design goals is to give my significant other, who by the way loves cats a lot more than me, the option to add cats on the fly and also consume the cat pictures in other services, I require dynamic image optimization.

Requirements:

• On demand addition of new images
• Optimization for different width and webp / progressive JPEG
• Served from the edge for lowest latencies

Since I’ve been working a lot with Cloudflare, I of course checked out their Image offering. While the service would exactly fulfill my requirements, it costs 5€/m, which I currently can not afford. I thought, this was a good opportunity to build my own little image optimization service, that I could maybe even use in the future for other image-related projects.

Infrastructure overview

I rely on Cloudflare services to serve the optimized images. On pages, this Svelte website is hosted. For our API endpoints that this website is querying, I utilize Cloudflare workers. The optimized images are stored on the new Cloudflare R2 storage and an index is created on KV. Finally, I host the image optimization program on a Raspberry Pi at my place. It is connected with a Cloudflare tunnel to the internet. Any other device that has computing power and is accessible via the internet is alright.

• (1): a user uploads a new image, for example via this site
• (2): the worker processes forwards the image to the image optimization server
• (3): the optimization server does its thing and serves the optimized images in a folder. The worker is notified where the optimized images can be found.
• (4): the worker fetches the images and stores them with a consistent naming scheme in
• (5): an object containing metadata to the optimized image (location in R2) are inserted into KV
